Butt welding Machine for Gabion Machine/Gabion Mesh Machine
Butt welding Machine for Gabion Machine/Gabion Mesh Machine
Model
UN-2

Item specifics

Power supply:
220V, Single phase, 50HZ
Grinder power supply:
220V, Single phase, 50HZ
Grinding wheel size:
125*25*12.7mm
Weight:
45kg
Packing dimension:
520*600*1200mm

Review

Description

Butt welding machine specifications

1) Power supply: 220V, Single phase, 50HZ
2) Power: 2KVA
3) Utilization factor: 15%
4) Welding times: 300 times/h
5)Adjustment grade: 8
6)Suitable for wire diameter: 0.8mm-5.0mm
7)Grinder power supply: 220V, Single phase, 50HZ
8)Grinder power: 120W
9)GrInder rotating speed: 2800 r/min
10) Grinding wheel size:125*25*12.7mm
11) Weight: 45kg
12) Packing dimension: 520*600*1200mm
Advantages of Butt welding machine
The Butt welding machine for  Gabion Machine/Gabion Mesh Machine is an essential auxiliary machine for the production of gabion  mesh.  It  is  designed  to  connect the two broken wire.

The Butt welding machine for Gabion Machine/Gabion Mesh Machine can efficiently and accurately weld the wires together, ensuring the stability and durability of the gabion mesh.

The Butt welding machine for Gabion Machine/Gabion Mesh Machine is easy to operate and requires minimal maintenance. it can greatly improve the production efficiency.
The Butt welding machine for Gabion Machine/Gabion Mesh Machine can reduce labor costs and improve safety, as it eliminates the need for manual welding.

Overall, the butt welding machine  for Gabion Machine/Gabion Mesh Machine  is an essential tool for producing high-quality and cost-effective gabion mesh.
Butt welding machine application site
Widely used in gabion mesh
Butt welding machine machine products
Widely used in gabion mesh
Frequently asked questions about Butt welding machine machine

Q:What Is A Butt Welding Machine  For Gabion Machine/Gabion Mesh Machine  ?

A:The butt welding machine is a machine that connect two broken wires by welding.

 Q:What Is The Suitable Wire Dia. Of The Butt Welding Machine For Gabion Machine?


A:The butt welding machine UN-2’s wire dia. Range is 0.8-5mm,it covers all gabion wire dia.

Q: What is the lifte time for the butt welding machine for Gabion Machine
A:The butt welding machine can use for many years,normally 5-6 years
