Gabion machine manufacturers
- Price
- US $45000-75000
- Model
- L-CNG4300 Gabion Machine manufacturers
- MOQ
- 1 set
Item specifics
- After-sales Service Provided
- Engineers available to service machinery overseas
- Out put
- 160 - 225M/H
- Color
- blue green or Customerized
- weight
- 15T
- wire diameter
- 2.0-4.0mm
- Breadth
- 2300-4300mm
- Power
- 11-33Kw
Review
Description
Detailed Product Description: The series gabion machines have been designed to make gabion mesh of various widths and mesh sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC, gabion coated wire is available.
We can manufacture Gabion Machine according to customer's request.
| 1.Mesh Size’s range from 50*70 mm To 176*200 mm； 2.We can design the machine to produce the mesh size according to customer’s request .But the mesh size should in the range of 50*70 mm To 176*200 mm； 3.Range of galvanized wire:2.0mm～4.0mm(for different mesh size pls find the parameter in the specification)； 4.Range of PVC coating galvanized wire: ≦5.0mm； 5.Our motor adopt Frequency Motor； |
|---|
Main Technical Parameter
Mesh Size (mm) | Max. Breadth (mm) | Max.Dia of Weaving wire(mm) | Max.Dia of Bordering Wire(mm) | Max Weaving- vein No. | Power (kw) | Theoretical Manu- facturing speed | Exterior Size(m) | Weight (T) | |
|---|---|---|---|---|---|---|---|---|---|
Mesh Hole Count/Minute | Meter/ Hour | L×W×H | |||||||
60×80 | 2300 | 2.7 | 4.0 | 3/5 | 11 | 42 | 165 | 5.2*1.4*2.4 | 13 |
3300 | 2.7 | 4.0 | 3/5 | 15 | 42 | 165 | 6.2*1.4*2.4 | 14 | |
4300 | 2.7 | 4.0 | 3/5 | 30 | 42 | 165 | 7.2*1.4*2.4 | 15 | |
80×100
| 2300 | 4.0 | 4.0 | 3/5 | 11 | 42 | 225 | 5.2*1.4*2.4 | 13 |
3300 | 4.0 | 4.0 | 3/5 | 15 | 42 | 225 | 6.2*1.4*2.4 | 14 | |
4300 | 4.0 | 4.0 | 3/5 | 30 | 42 | 225 | 7.2*1.4*2.4 | 15 | |
100×150 | 2300 | 4.0 | 4.0 | 3/5 | 11 | 42 | 225 | 5.2*1.4*2.4 | 13 |
3300 | 4.0 | 4.0 | 3/5 | 15 | 42 | 225 | 6.2*1.4*2.4 | 14 | |
4300 | 4.0 | 4.0 | 3/5 | 30 | 42 | 225 | 7.2*1.4*2.4 | 15 | |
160×180 | 2300 | 4.0 | 4.0 | 3/5 | 11 | 42 | 250 | 5.2*1.4*2.4 | 13 |
3300 | 4.0 | 4.0 | 3/5 | 15 | 42 | 250 | 6.2*1.4*2.4 | 14 | |
4300 | 4.0 | 4.0 | 3/5 | 30 | 42 | 250 | 7.2*1.4*2.4 | 15 | |
176×200 | 2300 | 4.0 | 4.0 | 3/5 | 11 | 42 | 250 | 5.2*1.4*2.4 | 13 |
3300 | 4.0 | 4.0 | 3/5 | 15 | 42 | 250 | 6.2*1.4*2.4 | 14 | |
4300 | 4.0 | 4.0 | 3/5 | 30 | 42 | 250 | 7.2*1.4*2.4 | 15 |
Main Machine
Auxiliary
Wire Spiral Coiling Machine
Wire Spiral Coiling Machine Product
Netting Roll Winding Machine
Wire Tension Machine
Wire Pay-off
Gabion Machine Electric control box
Applications
